Miller® Series 35™ Two-Stage Helium and Nitrogen Gas Regulator, CGA-580
Miller® Series 35™ Two-Stage Helium and Nitrogen Gas Regulator, CGA-580
Regular price
$642.60 USD
Regular price
Sale price
$642.60 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Item Details
- Miller® Two stage inert regulator, 0-50 PSIG - Series 35™ Two-Stage regulators drop cylinder pressure to working pressure in two stages for consistent and accurate outlet pressure and flow regardless of inlet pressure. Recommended where outlet pressure and flow must be maintained without variation.
Features
- Gas Regulator
- Regulator Supply Type Cylinder
- Gas Service Helium
- Inert Nitrogen
- Stages Two Stage
- Inlet Connection CGA-580
- Outlet Connection 5/8 In.-18 RH Internal
- Delivery Pressure Range 50 ps
- Gauge Size 2 in
- Supply Pressure Gauge 4,000 psi, Max. Inlet Pressure 3,000 psi
- Body Material Solid Brass
- Diaphragm Material Neoprene
- Body Dia. 2.0 in
- Includes External Relief Valve
- Nickel-Plated Bonnet
- Sure Seat(TM) Filtered Seat
- Standards UL Listed
Product Attributes
Regulator Type
» 2 Stage RegulatorGas Service
» Helium» Nitrogen
Delivery Rate
» 0-50 PSIGInlet Connection
» CGA-580Outlet Connection
» 5/8"-18 RH InternalGauge Diameter
» 50 PSIG
